Premium A2 Fire

Basic Info.

Usage	External Wall, Curtain Wall, Interior, Advertising
Customized	Customized
Thicknesses of Aluminum	0.5mm
Fire Rated	A2
Width	Max 2.6m
Length	Max 3.6m
Transport Package	in Bulk & Wooden Package
Specification	1.22m x 2.44m or Customized
Trademark	Smont
Origin	China, Shandong
HS Code	7606129000
Production Capacity	20000 M^2 Per Month

Product Description

Basic information
Product Specifications
Coating and Performance Specifications

Aluminum Composite Panel
Widely used, bendable, foldable, various colors and styles

Model NO.	SMONT-001	Aluminum Skin Thickness	0.5mm, Customized Available
Fire Rated	A2	Specification	1220*2440mm, Customized Available
Core Material	Inorganic Fireproof Core(Non Plastic)	Width Available	900mm~1500mm
Origin	Shandong, China	Payment Term	T/T
Production Capacity	4000 Square Meters Per Day	HS Code	7606129000
Transport Package	Wooden Cases	Trademark	SMONT

Standard Size

1220 * 2440 * 6mm

Thickness Range

2mm~8mm

Length Range

Less than 6000mm

Width Available

900mm~1570mm

Aluminum Skin Thickness

0.1mm~0.8mm

Colors

We have more than 60 colors available, with customization options

Coating

PE, PU, PVDF, FEVE, NANO, Anti-bacterial, Anti-Static, Anti-Scratch, etc.

Packing

Wooden-box or in bulk

Delivery Date

Standard color: 7-10 days; Special color and width: 25 days

Attribute

Specification

Details

Thickness of Coating

PVDF paint ≥ 25μm

26μm to 28μm

Coating Flexibility (T-bend)

PVDF paint ≤ 2T

Color Difference

ΔE ≤ 2.0 (follow color sample)

ΔE < 2.0

Pencil Hardness

≥ HB

Chemical Resistance

5% HCL or 5% NaOH test in 24 hours

No change; ASTM D1308

Coating Adhesion

≥ 1 grade for 10*10mm² gridding test

1 Grade

Resist Solvent

No change for 200 times (MEK)

No change

Boiling Water Resistance

Coating no tear off for 2 hours boiling

No tear off

Peeling Strength/Stripping Strength

Average ≥ 7N/mm of 180ºC peel off for panel with 0.5mm alu.skin

7N/mm

Impact Test for Paint

50kg.cm impact -- paint no split for panel

No split

Abrasion Resistance (L/Mil)

ASTM D968

Temperature Resistance

-40ºC to +80ºC temperature without change of color tolerance, paint peel off, peeling strength average drop rate ≤10%

Change of gloss only, no paint peel off

Coefficient of Linear Thermal Expansion

100ºC temperature difference

2.4mm/n

Detergent Resistance (3%)

ASTM D2248

No change

Humidity Resistance (3000 hrs, 100% RH, 100ºF)

ASTM D2247

No change

Salt Spray Resistance (3000 hrs, 5% salt)

ASTM B117

No change

Resistance to Staining

4000H radiate in 800W/m² in humidity condition, glossiness deviation less grade 2, color difference ≤4.0

No change

Applications

Company Information
Professional Expert Of Aluminum Composite Panel Shandong SMONT Decorative Building Materials Co., Ltd.
Is one of the biggest decorative building materials company in China.
Specialized in producing decorative building materials such as Aluminum Composite Panel,
Aluminum Core Composite Panel, PVC Wall Panel. Production Packaging
